AIC 7004 NEMO

NEMO : New Environmental Mastering Option

  • Proven volumetric mechanical meter
  • Suitable for engines up to 515 KW / 700 HP
  • Accuracy better than +/- 1% over the range
  • Repeatability better than +/- 0.2% over the range
  • NPN open collector, up to 10 mA / 32 VDC
  • 0,7ms pulse width
  • 2000 pulses per liter
  • 2014/30/EU conformity
  • Size: 39 x 14 x 31 cm (filter included)
  • Weight: 13,8 kg
Technical info
AIC 4004 Veritas fuel flow meter

Technology

  • Proven volumetric mechanical meter
  • Integrated PT 1000 high sensitive temperature probe
  • Mass calculation according to DIN 51757 with AIC BC 3329
  • Instantaneous CO2 feedback with AIC BC 3329
  • For installation on the succion side of the engine
  • To be installed in vertical position only (max 30 angle)
  • Works on all engines

Accuracy

  • Accuracy better than +/- 1 % over the range.
  • Repeatability better than +/- 0.2 % over the range.

Pulse signal output

  • NPN open collector, up to 10 mA / 32 VDC.
  • 0.7 ms pulse width
  • 2000 pulses per liter

Electrical

  • 24 V operation.
  • Pump consumption: approx 50 Watts.
  • 30 mA consumption.
  • No interferences with existing vehicle on-board electronic (CAN-Bus).

Mechanical

  • Size: 39 x 14 x 31 cm (filter included)
  • Weight: 13,8 kg

The AIC 7004 NEMO is perfectly suited for :

  • R&D testing: vehicle fuel consumption monitoring for medium and large trucks, buses, construction, demolition and agriculture machines
  • Mobile tyre testing

Every AIC 7004 NEMO can be delivered with the following “ready to go” dedicated accessories :

  • BBC 3329 NEMO Board Computer
  • Signal cable for AIC BC 3329 NEMO (10 m)
  • AIC s1607 Pulse Convertor
  • Signal cable wire end free (3rd party logger) (10m)
  • Connector kit including various fittings and fuel hose
  • Mounting bracket
  • Transport case

The AIC 7000 NEMO can be ordered with the following options :

  • Third party calibration certification.
  • Bio fuel compatibility
